FLIR Image Streaming Configuration for A50/A70 Cores

SKU
T300390
Rating:
0%
(0)
Reward Points (?)

Logged in, worth £6.38, read more.

:
638
£382.80 £319.00
Advice & Support
Price Match Request

For use with FLIR’s A50 or A70 Thermal Camera Cores (sold separately), the FLIR Image Streaming Configuration provides camera control, image streaming over Ethernet, and compatibility with software applications designed for raw thermal data collection.

The FLIR Image Streaming Configuration delivers simple integration using non-proprietary industry-standard connectivity, as well as data and image streaming. It is compatible with GigE Vision and GenICam which facilitates thermal/ visual image streaming into third-party machine vision applications and enables camera control. Moreover, the FLIR Image Streaming Configuration (Advanced Configuration ONLY) offers full support for compressed radiometric streaming using FLIR Atlas SDK.

When used with the FLIR A50/A70 Thermal Camera Core, the FLIR Image Streaming Configuration is ideal for optimising process control and quality assurance to improve yield, product quality, efficiency, and cost-effectiveness.

FLIR Image Streaming Configuration Key Features

  • Designed for use with FLIR’s A50 or A70 Thermal Camera Cores
  • Provides camera control capabilities
  • Image streaming over Ethernet
  • Analytics
  • Compatible with software applications designed for raw thermal data collection
  • GigE Vision and GenICam compatible: enables camera control and visual/ thermal streaming into third-party machine vision applications
  • Full support for compressed radiometric streaming using FLIR Atlas SDK (Advanced Configuration ONLY)
  • Simple integration using non-proprietary industry-standard connectivity
  • Optimise process control and quality assurance to improve yield, product quality, efficiency, and cost-effectiveness

What’s Included?

  • FLIR Image Streaming Configuration

Please note that the Smart Sensor Configuration is a programming option. It is incorporated into the camera core at the point of manufacture. Therefore it MUST be purchased with a FLIR A50 or A70 Thermal Camera Core (sold separately).

Part Code

FLIR Image Streaming Sensor Configuration for A50/A70 Cores Technical Specifications

Image & Optical Data Standard Configuration Advanced Configuration
IR resolution 464 × 348 (A50), 640 × 480 (A70)
Visual Resolution 1280 × 960 pixels (optional)
Thermal Resolution A70: 29°: <45 mK, 51°: <45 mK, 95°: <60 mK
A50: 29°: <35 mK, 51°: <35 mK, 95°: <45 mK
Focus Fixed, adjustable with included focus tool
Spatial Resolution
(IFOV)
A50: 29°: 1.2 mrad/pixel, 51°: 2.1 mrad/pixel, 95°: 4.0 mrad/pixel
A70: 29°: 0.84 mrad/pixel, 51°: 1.5 mrad/pixel, 95°: 2.9 mrad/pixel
FOV Options 29°, 51°, 95°
Detector Pitch A50: 17 µm, A70: 12 µm
Spectral Range 7.5–14.0 µm
Frame Rate 30 Hz
Measurement
Object temperature
range
-20°C to 175°C (-4°F to 347°F)
175°C to 1000°C (347°F to 1832°F)
20°C to 175°C (-4°F to 347°F)
-20°C to 250°C (-4°F to 482°F)
175°C to 1000°C (347°F to 1832°F)
Accuracy ±2°C (±3.6°F) or ±2% of reading, for ambient temperature 15°C to
35°C (59°F to 95°F) and object temperature above 0°C (32°F)
Video Streaming,
RTSP Protocol
Unicast Yes
Multicast Yes
Radiometric RTSP No Compressed JPEG-LS
(FLIR Radiometric)
Multiple Image Streams Yes, visual camera option needed (P/N T300295)
Video Stream 0
Streaming Resolution 640 × 480 pixels
Source Visual / IR / MSX® / FSX® (visual camera is optional)
Contrast Enhancement FSX® / Histogram equalization (IR only)
Overlay With/Without
Encoding H.264, MPEG4, or MJPEG
Video Stream 1
Streaming Resolution 1280 × 960 pixels
Source Visual (visual camera is optional)
Overlay No
Encoding H.264, MPEG4, or MJPEG
Video streaming, GVSP (GigE Vision Streaming Protocol)
Unicast Yes
Multicast Yes
Dual Video Streams No (either IR, Visual, MSX, FSX or Radiometric 16 bit)
Visual Resolution 640 × 480
Pixel Formats YUV411, MONO8, MONO16
Radiometric Resolution A50: 464 × 348, A70: 640 × 480
Temperature Linear 16-bit Yes
Compressed JPEG-LS No Yes
Ethernet
Ethernet Communication GigE Vision, GenICam (SFNC 2.4)
Connector Types M12 8-pin X-coded, female; RP-SMA, female
Ethernet Interface Wired, Wi-Fi (optional)
Ethernet Power Power over Ethernet, PoE IEEE 802.3af class 3
Ethernet Protocols IEEE 1588, SNMP, TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP,
sftp (server), FTP (client), SMTP, DHCP, MDNS (Bonjour), uPnP
Ethernet Standard IEEE 802.3
Ethernet Type 1000 Mbps
Digital Input/Output
Connector Type M12 Male 12-pin A-coded (shared with external power)
Digital Input 2× opto-isolated, Vin (low) = 0 to 1.5 V, Vin (high) = 3 to 25 V
Digital Output 3× opto-isolated, 0 to 48 V DC, max. 350 mA (derated to 200 mA
at 60°C). Solid-state opto relay, 1× dedicated as fault output (NC)
Power
Power Consumption 7.5 W at 24 V DC typical, 7.8 W at 48 V DC typical,
8.1 W at 48 V PoE typical
External Power Operation 24/48 V DC 8 W max
External Voltage Allowed range 18 V to 56 V DC
Power Connection M12 12-pin A-coded, male (shared with Digital I/O)
Wi-Fi
Connector Type Female RP-SMA
