Flir C8 Compact Thermal Imaging Camera (9Hz)
Free Gift
- Streaming over USB
- 2m Drop Test
- IP54 Rated
- Wi-Fi & Bluetooth Connectivity
SKU
18801-0101
MPN
18801-0101
The FLIR C8 has a 320 × 240 thermal resolution, MSX technology, and built-in FLIR Ignite connectivity. Your detailed images are uploaded directly to the cloud. The C8 also features an intuitive 3.5-inch touchscreen and USB streaming capabilities.
Ignite Pro takes it further with ready-made inspection templates, enabling consistent analysis and professional reports without unnecessary admin work. Whether diagnosing hot fuses, insulation gaps, or plumbing leaks, the C8 is a pocket-sized tool designed to keep you ready for any challenge.
Flir C8 | Compact Thermal Camera
Key Features
- Compact, pocket-sized form factor
- 320 x 240 IR Resolution
- NETD <50 mK Sensitivity
- 5MP Visual Camera
- 3.5” Touch Display
- LED flashlamp
- WIFI & Bluetooth Connectivity
- MSX (Multi-Spectral Dynamic Imaging)
- Text annotations
- 1 touch level/span
- Box, cold spot, hot spot temperature measurement
- FLIR Ignite Connectivity (automatically upload images to Ignite for reporting and analysis)
- Enhanced Image quality
- 35°Horizontal Field of View (HFOV)
- Advanced reporting templates within FLIR Ignite PRO
- Increased accuracy with +/2 -2°C @ 0°C - 450°C
- 450°C Max Object Temperature
- Sensitivity increased to NETD 50 mk
- Isotherm alarming for temperature threshold imaging requirements
- Streaming over USB
- 2m Drop Test
- IP54 Rated
- Reliable, Faster Inspections
- Seamless Cloud Integration
- Simplified Reporting
- Compact and Rugged Design
What's Included?
- Flir C8
- Wrist Strap Lanyard
- Pouch
- USB Type-C cable
- Printed documentation
Offers
Free Accessory
- TPI 725L Pocket Combustible Gas Leak Detector - TPI-725L, typically £39.95
Technical Information
Specification
| IMAGING AND OPTICAL | |
|---|---|
| IR resolution | 320 x 240 pixels |
| Thermal sensitivity/NETD | <50 mK |
| Field of View (FOV) | 35° x 27° |
| Minimum Focus Distance | 0.4 m (1.3 ft) |
| Spatial Resolution (IFOV) | 2.0 mrad/pixel |
| F-number | 1.4 |
| Image Frequency | 9 Hz |
| Focus | Focus free |
| Digital Zoom | Yes, zoom pinch, 1 to 4x continuous |
| DETECTOR | |
| Detector Type | Focal plane array, uncooled microbolometer |
| Spectral Range | 7.5–13 μm |
| Detector Pitch | 12 μm |
| IMAGE PRESENTATION | |
| Display Resolution | 640 x 480 pixels |
| Screen Size | 3.5 in |
| Aspect Ratio | 4:3 |
| Auto Orientation | Yes |
| Touch Screen | Yes, capacitive |
| Display Technology | IPS |
| Image Adjustment | Automatic level and span / Manual level and span / 1-Touch level and span |
| Image modes | Infrared image / Visual image / MSX / Picture-in-picture (IR area on visual image) |
| Gallery | Yes, incl. thumbnails and custom folder structure |
| MEASUREMENT | |
| Object Temperature Range | -20°C to 450°C (-4°F to 842°F) |
| Accuracy at Ambient Temperature | 0°C to 100°C (32°F to 212°F): ±2°C (±5.5°F) 100°C to 450°C (212°F to 842°F): ±2% |
| MEASUREMENT ANALYSIS | |
| Measurement Functions | Spot / Box with max. and min. / Isotherm |
| Measurements Correction | Emissivity; matt/semi-matt/semi-glossy + custom value / Reflected apparent temperature / Atmospheric compensation |
| Colour Palettes | Iron, Grey, Rainbow, Arctic, Lava, Rainbow HC |
| SERVICE FUNCTIONS | |
| Camera Software Update | Automatic over Wi-Fi / USB via computer |
| STORAGE OF IMAGES | |
| Storage Media | Built-in |
| Image Storage Capacity | >5000 sets of images |
| Image File Format | Standard JPEG, 14-bit measurement data included |
| IMAGE ANNOTATIONS | |
| Text | Soft keyboard on touchscreen, auto-prompt for note when image is saved |
| VIDEO STREAMING | |
| Non-radiometric Video Streaming | Yes, MSX, Thermal, Visual, Picture-in-Picture. USB video class colourised, uncompressed with overlay 9 Hz. |
| DIGITAL CAMERA | |
| Resolution | 5 MP |
| Focus | Fixed |
| Field of View | 71.5° x 56° (84° diagonal) |
| Video Lamp | Yes |
| DATA COMMUNICATION INTERFACES | |
| Wi-Fi | 802.11 a/b/g/n (2.4 and 5 GHz) |
| USB | USB 2.0, Type-C connector |
| Bluetooth | Yes |
| POWER SYSTEM | |
| Battery Type | Rechargeable lithium-ion battery (built-in) |
| Battery Operating Time | 3 hours |
| Charging System | USB-C |
| Charging Time | 2 hours |
| Power Management | Adjustable stand-by and automatic shut-down |
| ENVIRONMENTAL DATA | |
| Operating Temperature Range | -10°C to 50°C (14°F to 122°F) |
| Storage Temperature Range | -40°C to 70°C (-40°F to 158°F) |
| Humidity (Operating and Storage) | IEC 60068-2-30/24 h 95% relative humidity 25°C to 40°C (77°F to 104°F) / 2 cycles |
| Relative Humidity | 95% relative humidity 25°C to 40°C (77°F to 104° F) non-condensing |
| EMC | EN 301 489-1 RED EN 301 489-17 FCC 47 CFR Part 15 B, Class B |
| Encapsulation | Camera housing and lens: IP54 (IEC 60529) |
| Vibration | Designed for 2 m (6.56 ft) |
| Environmental Safety | REACH Regulation EC 1907/2006 RoHS2 Directive 2011/65/EC WEEE Directive 2012/19/EC Proposition 65 |
| PHYSICAL DATA | |
| Weight (including battery) | 0.19 kg (0.42 lb) |
| Size (L x W x H) | 138 x 84 x 34 mm (5.4 x 3.3 x 0.94 in) |
| Tripod Mounting | UNC ¼″-20 |
| Housing Material | PC and ABS, partially covered with TPE / Aluminium |
Document Downloads
Additional Information
SKU
18801-0101
Manufacturer Part Code
18801-0101
Country of Origin
Estonia
Flir C8 Compact Thermal Imaging Camera (9Hz)
