Octopus Energy Ltd has purchased a number of these cameras for their Octo Assist Initiative. As part of this program, Octopus Energy is loaning thermal cameras to its customers, enabling them to identify sources of heat loss around their homes in a bid to reduce their energy wastage and bills.
Read about the role Teledyne FLIR One Pro Thermal Cameras are playing in the Octo Assist Initiative:
PASS Proudly Provides FLIR Thermal Cameras for Octopus Energy Home Efficiency Surveys
The Teledyne FLIR One Edge Pro Wireless Thermal Camera is an innovative inspection solution that transforms your iOS/Android smartphone or tablet into a thermal imager capable of capturing crisp infrared images and videos. Capable of measuring temperatures up to 400°C and equipped with a 160 x 120px thermal resolution, the Teledyne FLIR One Edge Pro makes inspecting targets that are out of reach easy. Additionally, it can be clipped to your smartphone or tablet enabling one-handed inspections. FLIR's VividIR™ function, which combines multiple frames, and MSX™ mode, which overlays digital details onto thermal images, ensure you take sharp, clear thermal images and videos. Furthermore, FLIR Ignite™ technology allows you to upload thermal media to FLIR’s Ignite Cloud Service immediately for storage, organisation, editing, or sharing. The Teledyne FLIR One Edge Pro Wireless Thermal Camera is also compatible with FLIR’s Thermal Studio Software, a state-of-the-art analysis and reporting program.
Teledyne FLIR One Edge Pro Wireless Thermal Camera Key Features
- A wireless thermal imaging module compatible with iOS and Android smartphones/tablets
- Inspect targets that are out of reach
- Clip to your smartphone/tablet to conduct one-handed inspections
- FLIR VividIR™ function
- FLIR MSX™ mode
- 160px x 120px thermal resolution
- Measure temperatures up to 400°C
- Capture sharp, high-quality thermal images and videos
- Compatibility with FLIR apps improves inspection efficiency and makes inspections easily scalable
- Step-by-step guidance for a range of FLIR-specific apps
- Compatible with FLIR’s Thermal Studio Software, an analysis and reporting program
- Compatible with FLIR’s Ignite Cloud Service: instantly upload media to the Cloud for storage, organisation, editing or sharing
- Rugged design
- Battery life: 1.5 hours
- An innovative inspection solution that transforms your smartphone/tablet into a thermal imager
What’s Included?
- Teledyne FLIR One Edge Pro Wireless Thermal Camera – iOS & Android
- Relevant Documentation
Teledyne FLIR One Edge Pro Wireless Thermal Camera – iOS & Android Technolgy Specifications
Thermal Resolution | 160 × 120 (19,200 pixels) |
Battery life | Approximately 1 hour 30 minutes |
Object Temperature Range | -20°C — 120°C (–4°F — 248°F) and 0°C — 400°C (32°F — 752°F) |
Accuracy | ±3°C (5.4°F) or ±5%. Applicable 60 sec after start-up when the unit is within 15°C to 35°C (59°F to 95°F) and the scene is within 5°C to 120°C (41°F to 248°F) |
Operating Temperature | -10°C to 50°C (14°F to 122°F), battery charging 0°C to 45°C (32°F to 113°F) |
Spot Meter | Hottest, Coldest and 3 spot measurement |
Imaging & Optical | |
Adjustable MSX distance | 30 cm - Infinity |
Focus | Fixed 30 cm — Infinity |
Frame Rate | 8.7 Hz |
HFOV/VFOV | 54° ±1° / 42° ±1° |
Image Modes | Infrared, visual, MSX |
Palette | Gray (white hot), Hottest, Coldest, Iron, Contrast, Arctic, Lava and Color Wheel |
Shutter | Automatic/Manual |
Thermal Resolution | 160 × 120 (19,200 pixels) |
Thermal Sensitivity/NETD | 70 mK |
Thermal Sensor | Pixel size 12 µm, 8 — 14 µm spectral range |
Visual Resolution | 640 × 480 |
VividIR | Yes |
Power | |
Battery charge time | 60–90 min for fully charged 15 min charging, from empty battery, gives 40 min operating time |
Battery life | Approximately 1 hour 30 minutes |
Charging Method | Female USB-C (5V/1A) |
Measurement & Analysis | |
Accuracy | ±3°C (5.4°F) or ±5%. Applicable 60 sec after start-up when the unit is within 15°C to 35°C (59°F to 95°F) and the scene is within 5°C to 120°C (41°F to 248°F) |
Measurement Corrections | Emissivity; Reflected apparent temperature (22°C / 72°F) |
Object Temperature Range | -20°C — 120°C (–4°F — 248°F) and 0°C — 400°C (32°F — 752°F) |
Spot Meter | Hottest, Coldest and 3 spot measurement |
General | |
Battery charge monitor | 0 — 100% |
Clip Span | 130 mm (min) / 195 mm (max) |
Device Compatibility | iOS or Android smartphones and tablets |
Dimensions (H x W x D) | 37.5 mm × 35 mm × 149 mm (1.5 in × 1.4 in × 5.9 in) |
Remote Operation | Up to 30 m (100 ft) from smart device via Wi-Fi |
Weight | 153 g (5.4 oz) |
Environmental & Certifications | |
Certifications | RoHS, CE/FCC, CEC-BC, EN62133, UL1642, WEEE 2012/19/EU |
Drop test | Drop from 2 m (6.56 ft) |
Emissivity Settings | Matte: 95%, Semi-Matte: 80%, Semi-Glossy: 60%, Glossy: 30% |
Non-Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
Operating Temperature | -10°C to 50°C (14°F to 122°F), battery charging 0°C to 45°C (32°F to 113°F) |
Communication & Data Storage | |
Bluetooth | Yes |
Capture modes | Video, Still image |
Charging | Female USB-C (5V/1A) |
File Formats | Radiometric JPG, MPEG-4 (file format MOV (iOS), MP4 (Android)) |
WiFi | IEEE 802.11 a/b/g/n |
Reviews
SKU | 11002-0201 |
---|---|
Manufacturer Part Code | 11002-0201 |
Country of Origin | Estonia |
